Outdoor Area Reflector
STR / Gamma
Among the most energy-efficient LED reflectors available. Designed for large outdoor areas in low, medium, and high radiation zones — including waste management buildings, spent fuel dry storage areas, and outdoor nuclear facilities requiring high-mast illumination. Nanotechnology optics with 98% reflectivity and a designed lifetime exceeding 20 years. Available in indoor and outdoor (IP66) versions.
| LED Efficiency | 210 lm/W |
| Overall Efficiency | 160 lm/W |
| Mounting Height | 8–30m |
| Optics Reflectivity | 98% (nanotechnology) |
| Outdoor Version | IP66 |
| LED Redundancy | 100% single-source failure resistant |
| Driver | Proprietary, encapsulated in the reflector body |
| Warranty / Lifetime | 5 years / >20 years designed |
Reference Installation
NEK Krško Nuclear Power Plant — Switchyard Area
40 STR ULTRA reflectors mounted on 6 towers at 30m height, illuminating the switchyard area adjacent to the nuclear power plant. Total connected power of 5.4 kW.
40
Reflectors
30m
Tower height
6
Towers
5.4kW
Total power
